The Mosmatic 58.163 DYF is a high-pressure brass swivel featuring a 3/8″ NPTF inlet and a G3/8″ BSPP (male) outletmaking it ideal for connecting NPT-threaded lines to BSP-threaded tools or accessories.
This 360 maintenance-free swivel supports up to 4000 psi and includes a carbide seal, sealed bearing system, and weep holes for early detection of seal wear. Its nickel-plated brass housing ensures excellent corrosion resistance in demanding cleaning environments.
Applications
-
Pressure washers with BSPP connections
-
Surface cleaners and wash booms
-
Car wash arms and rotating nozzles
-
Industrial fluid systems needing NPT-to-G thread
Features
-
360 full rotation
-
Carbide seal with weep hole alert
-
Nickel-plated brass body for corrosion resistance
-
Maintenance-free, sealed bearing system
-
Rated up to 4000 psi
-
Ideal for NPT-to-BSPP transitions
Specs
Product Type: High-pressure swivelDYF
Part Number: 58.163
Pressure: 4000 psi
Temperature: 250F
RPM: max. 2,000 rpm
Material Type: Brass, nickel plated
Inner Part: Stainless steel
Seal: Carbide
Throughput / Medium: pH 312 / filtered 10 microns / compressed air (290 psi)
Thread In (G1): 3/8″ NPTF
Thread Out (G2): G3/8″ M
Nominal Width (NW): 1/4″
Wrench Size 1 (SW1): 0.87″
Wrench Size 2 (SW2): 0.75″
Diameter (D): 2.36″
Length 1 (L1): 1.49″
Length 2 (L2): 0.39″
Weight: 13.2 oz
